Description
• 12, 6 and 3 channel resting ECG
• 8″ LCD color touch screen
• Write-out of all 12 channels among each other or in packages (2×6, 3×4)
• Clearly arranged, high printout in DIN A4 format
• Printout of rhythm derivarion for 3- and 6-channel settings
• Manual ECG monitoring or 10 seconds memory ECG for interpretation
• Automatic interpretation recommendation
• Interpretation function distinguishes between 25 diagnostic cases based on Minnesota protocol
Measurement parameters: HF, PR Interval, Duration of QRS-complex, QT/QTC, electrical R/QRS/T-axis, RV5/SVI amplitude
Battery: Lithium-ion – Approx. 5 gours runtime when fully charged or up to 500 printed ECG reports in automatic mode
Connection: 1x SD card / 2x USB / 1x RJ-45 (network)
Included are:
• ECG patient cable
• Power cord
• 6x chest wall suction electrodes
• 4x extremity clamb electrodes
• Manual
• Paper
• ECG gel
